GSLG-A Slide Gate Operator Installation Guide - 29 - P1222 Revision X5 6-22-2011
MODEL GSLG-A MECHANICAL PARTS LIST
REF. # PART # DESCRIPTION
2120-359-BT Complete Enclosure with Door Assembly
1 2120-144-BT Enclosure without Door
2120-360-BT Complete Door and Lock Assembly
2300-716 Stop/Reset Button Cover
2500-2192 C-Face Brake, 115V
2500-2397 C-Face Brake, 208/230/460V
5 2110-265 Rail Assembly
15 2100-573 Spacer Plate
2100-661 Back Brace
12 2100-1738 Drive Shaft, 1”
48 2400-501 Retaining Ring
9 2200-274 Bearing, 1”
43 2100-1737 Pillow Block Retaining Plate
40 2200-042 Sprocket, 48 B 15, 1” bore
2200-015 Shaft Collar, 1”
7 2120-388 Torque Limiter Assembly, 5-1/2”
7A 2100-1650 Plate with Solid Pin Groove
7B 2100-1661 Keyed Plate
7C 2300-390 Friction Disc (pair)
7D 2200-817 Belleville Washer
7E 2100-1621 Belleville Washer Retaining Disc
7F 2100-1622 Adjustment Nut
7G 2400-407 Brass Tipped Set Screw
7H 2400-416 Dowel Pin
7I 2100-529 Woodruff Key
8 2210-004 Sprocket, 40-A-48, with Bearing
42 2200-886 Drive Sprocket, 50-B-20, 1” Bore
2110-788 Gear Reducer/Disconnect Assembly
2 2200-920 Gear Reducer, 15:1
19 2120-132 Shifter Lever Assembly
18 2110-362 Shifter Lever Fulcrum Assembly
37 2100-551 Shifter Lever Rod
38 2400-169 Pal Nut
20 2100-1133 Locking Lever Plate
28 2100-910 Locking Lever
41 2200-291 Shifter and Locking Lever Spring
14 2200-014 Shaft Collar, 1”
11 2110-364 Sprocket, 40 A 24, with Bearing
30 2200-549 Disconnect Collar, 1” (keyed)
31 2110-131 Shifter Block
2400-133 Key, 1/4” x 1/4” x 2-1/4”
32 2200-115 Disconnect Spring
44 2510-248 Stop/Reset Button & Bracket Assembly
2100-1760 Stop/Reset Button Mounting Bracket
2500-1495 Stop/Reset Button
33 2400-308 Fender Washer, 3/8”
34 2400-017 Flat Washer, 3/8”
35 2400-016 Lock Washer, 3/8”
36 2400-014 HHCS, 3/8”-16 x 1”
16 2110-700 Idler Assembly
2300-697 UHMW Idler Wheel
2100-1731 Idler Shaft
6 2520-173L Rotary Limit Box Assembly
2500-764 Limit Switch
2100-057 Standard Limit Shaft
2200-030 Limit Nut
2100-261 Detent Plate
2110-162 Limit Box Enclosure with Cover
2100-756 Limit Box Cover only
2200-029 Flange Bearing, 1/2” ID
2200-193 E-Ring, 1/2”
2400-203 Spring Washer, 1/2”
REF. # PART # DESCRIPTION
2200-042 Limit Drive Sprocket, 48-B-15, 1” bore
For drives up to 34 feet wide:
39 2200-008 Limit Box Sprocket, 48-B-10, 1/2” bore
2200-922 #48 Chain, 25 Links
For drives from 35 to 49 feet wide:
2200-041 Limit Box Sprocket, 48-B-15, 1/2” bore
2200-200 #48 Chain, per foot, 27 Links
For drives 50 to 65 feet wide:
2200-276 Limit Box Sprocket, 48-B-20, 1/2” bore
2200-654 #48 Chain, per foot, 29 Links required
For drives over 65 feet wide:
2200-432 Limit Box Sprocket, 48-B-30, 1/2” bore
2200-654 #48 Chain, per foot, 32 links required
2200-010 #48 Master Link
2200-605 #40 Chain, 37 Links
2200-006 #40 Master Link
17 2100-657-BT Rain Cover
24 2200-221 #50 Roller Chain, per foot
2200-111 #50 Master Link
25 2100-258 Chain Pin
26 2200-306 Tension Spring
22 2100-2007 Gate Bracket
27 2400-090 Hex Nut, 1/2”
23 2400-170 Gate U-Bolt
21 2400-038 Mounting U-Bolt
2500-867 Alarm, 24VAC
C-FACE MOTORS
4
2500-2307 1/2 HP, 115 VAC, 1 Phase
2500-2308 1/2 HP, 208/230 VAC, 1 Phase
2500-2309 3/4 HP, 115 VAC, 1 Phase
2500-2310 3/4 HP, 208/230 VAC, 1 Phase
2500-2311 1 HP, 115 VAC, 1 Phase
2500-2312 1 HP, 208/230 VAC, 1 Phase
2500-2313 1/2 HP, 208/230/460V, 3 Phase
2500-2314 3/4 HP, 208/230/460V, 3 Phase
2500-2315 1 HP, 208/230/460V, 3 Phase
CAPACITORS
2500-2336 Capacitor for 2500-2307 Motor
2500-2337 Capacitor for 2500-2308 Motor
2500-1926 Capacitor #1 for 2500-2309 Motor
2500-1930 Capacitor #2 for 2500-2309 Motor
2500-1931 Capacitor for 2500-2310 Motor
2500-2338 Capacitor for 2500-2311 Motor
2500-1932 Capacitor for 2500-2312 Motor
To Next Page
