Link 1245 - 1/3HP User Manual

9
UP
CEILING MOUNT ONLY
7
11
13
14
12VDC
3
LIGHT
LOCK
1
2
4
5
NOTICE
6
8
10
12
14
15
2
1
3
4
5
RAIL GREASE
NO. 83A4
6
Rail Assembly Parts
Installation Parts
32
KEY PART
NO. NO. DESCRIPTION
1 1A995 Master link kit
2 41A4813 Chain pulley bracket
3 41A3489 Complete trolley assembly
4 183B99 One-piece T-rail
5 41D3484 Full chain assembly
6 83A4 Rail grease
KEY PART
NO. NO. DESCRIPTION
1 41A4202-5A Multi-function door control panel
2 41A4166 Lighted door control button
3 10A14 12V battery
4 29C128 Transmitter visor clip
5 41A3984-13 Transmitter case, cover & screw only
6 41A2828 Manual rope & handle assy.
7 217A238 2-Conductor bell wire, white & white/red
8 41A5047 Door bracket w/clevis pin & fastener
9 41A4353 Header bracket w/clevis pin & fastener
10 41A4373A Safety sensor kit
(receiving and sending eyes)
with 3' 2-conductor bell wire
11 178B34 Straight door arm section
12 12B483 "C" Wrap bracket
13 178B35 Curved door arm section
14 12B484 Square hole mounting bracket
15 12B485 Slotted mounting bracket
NOT SHOWN
41A2770-2 Installation hardware bag
(see page 5)
41A4116 Safety sensor hardware (see page 5)
114A1952 Owner's manual
Repair Parts

Link 1245 - 1/3HP Specifications

General

Brand	Link
Model	1245 - 1/3HP
Category	Garage Door Opener
Language	English
