Installation Guide
2 18-HD99D1-1A-EN
2. Zoning Overview
Contents
1. Safety
s
s
WARNING
!
This information is intended for use by
individuals possessing adequate backgrounds
of electrical and mechanical experience. Any
attempt to repair a central air conditioning
product may result in personal injury and/or
property damage. The manufacturer or seller
cannot be responsible for the interpretation of
this information, nor can it assume any liability
in connection with its use.
s
s
WARNING
!
LIVE ELECTRICAL COMPONENTS!
During installation, testing, servicing, and
troubleshooting of this product, it may
be necessary to work with live electrical
components. Failure to follow all electrical
safety precautions when exposed to live
electrical components could result in death or
serious injury.
SPECIFICATION DESCRIPTION
Model ZZON2PNLA200ZA
Product Link Zone Panel
Size 6.2” width x 5.0” height x 1.2” depth
Storage Temperature -40 °F to + 175 °F, 5% to 95% RH non-condensing
Operating Temperature -40 °F to + 150 °F, 5% to 95% RH non-condensing
Input Power* 24VAC from external transformer (Range: 18~30VAC)
Power Consumption 2VA for each Zone Panel (damper VA not included)
Wire Usage Minimum 18-guage NEC approved control wiring
Communications CAN BUS /CAN System Bus
* On every application, 24VAC loads should be reviewed to be sure the indoor unit control power
transformer is adequately sized.
1. Safety ............................................................2
2. Zoning Overview ..........................................2
3. General Information ......................................3
4. Link Zoning Preparation and Mounting ......4
5. Zoning Components .....................................5
6. Pre-congurationzoningchecklist ..........13
7. Trane/AS Diagnostics Mobile App ............14
8. Link Zoning Commissioning .......................18
9. Zone 1 Sensor Setup ....................................28
10. Sensor Assignment ....................................29
11.ZoningAirowTest ................................... 33
12. Zoning Settings and Parameters .............37
13. Zone Panel Replacement .......................... 39
