Technical parameters:
Type Link Gate A Premium
Operating position various
Operating conditions temperature: +5° C ÷ +40° C,
Humidity: 10% ÷ 80% at 30° C
Dimensions (mm) 140*97*37
Weight 215g
Part of power supply
Supply voltage 8-12V (AC/DC) (adapter)
Protection thermal fuse in adapter
Safety group ČSN EN 60950 group 2
Analogue telephone line
Telephone interface 2-wires
Telephone connector RJ 11
Impedance 600 Ω ± 20%
Dial tone DTMF t
t > 30 ms
Billing 12/16 kHz
Start and end of connection Polarity reversal
Supply conduction symmetrical 24V
Current loop max 29 mA
Resistance of subscribers conduction max. 500 Ω
Ringing 55 V
ef / 50 Hz
Signalization 425 Hz ±20Hz
CLIP FSK Bell
GSM:
Mobile network Quad band (850/900/1800/1900Mhz)
Provider according SIM card (3V and 1.8 V)
USB version 1.1, virtual COM
