Linksys EA6350 User Manual

2
Product Overview
Linksys EA-Series
• Internet port—Connect an Ethernet cable to this yellow port and to your
modem.
• Reset button—Press and hold for 10 seconds (until the port lights blink
at the same time) to reset the router to its factory defaults. You can also
restore the defaults using Linksys Smart Wi-Fi.
• Power port—Connect the included AC power adapter.
• Power button—Press | (on) to turn on the router.

Linksys EA6350 Specifications

General

Color	black
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100
Wireless Standard	ac
Gigabit Ethernet Speed	yes
Antennas	2
Parental Control	yes
Firewall	other
Data Encryption	yes
Encryption Type	wpa2
Ports	rj-45
Built In Modem	yes
System Requirements	pc: windows xp with service pack 3, vista with service pack 1 or later, 7 or 8; mac: os x leopard v10.5.8 or later, snow leopard v10.6.1 or later, lion v10.7 or mountain lion v10.8; wi-fi capability; cd or dvd drive

Weight and Dimensions

Height	9.1 inches
Width	12.6 inches
Net Weight	2 pounds
