Specifications
Antenna inputs FM: 75Ω coaxial connector.
AM: Screw terminals
Outputs Two pairs RCA phono connectors.
Output impedance 200Ω
Minimum load: 1kΩ total
Output levels FM: 775mV rms into 1kΩ at 75kHz peak
deviation.
AM: 775mV rms into 1kΩ at 100% modulation.
Mains fuse 220V and 240V: T400mA 50/60Hz
100V and 120V: T800mA 50/60Hz.
Power consumption 20VA approx.
Size 320mm x 326mm x 80mm
(12.6" x 12.8" x 3.2") (W x D x H)
Weight 3.3Kg (7.3lb)
