Lino PL2 TC2 V - Page 85

EN
85
• Apply the supplied one-sided selfad-
hesive sealing tape all the way around
the lower edge of the cooktop.
• Screw the 4 worktop mounting brack-
ets on to the side walls of the appli-
ance.
• Insert the appliance into the aperture.
Worktop
mounting bracket
Self-adhesive
sealing tape
min 20
20
25
5
490
min 50
min 50
270
290
47,5
520
min 250
min 20
20
25
50
5
490
min 50
min 50
270
290
47,5
520
HOB
HOB
Separator
Separator
