Wiring procedures
I
f your accessory has wire leads instead of terminal connections, you
can connect each of the two controller wires to each of the accessory
wire leads by twisting them together. Insulate the twisted wire connec-
tions from each other with wire nuts or electrical tape.
For multiple accessories, the use of terminal strips or buss wires is rec-
ommended. Connections can be spliced together as well.
See the wiring diagrams below for examples of various wiring
connections.
Example of spliced connections using wire nuts.
Example of buss wire connections.
Accessory 1 Accessory 2 Accessory 3
