Example of terminal strip connections.
Accessory 1
Accessory 2
Plug power pack into
standard wall outlet
Plug this end into
back of controller.
TO ACCESSORY CLIPS, BINDING
POSTS
, OR LEADS
After you’ve connected your accessory to the controller, you will then
need to insert the power pack connector into the back of your con-
troller, and plug the power pack into a standard outlet. See the illus-
tration below.
