2
D. EVO-6 DBU Design
D-1 440V
Power Input
Terminal
Fault Lamp
Power Lamp
Brake Lamp
Input Voltage
Setting Switch
Master/Slave Terminal
Relay Output Terminal
Master/Slave
Switch
Brake Resistor Terminal
