7
G-2 Single installation
G-3 Multiple installation (master-slave parallel)
G-4 Terminal Wire Gauge
Terminal
AWG, kcmil
mm
2
Screw
Suggestion
Available
Suggestion
Available
+(P), -(N),
B1, B2
10
14 ~ 8
2.58
1.63 ~ 3.26
M3
M1, M2, S1, S2,
RA, RB, RC
20
24 ~ 16
0.8
0.5 ~ 1.29
M2
