LiteOn EVO600043S3D7E20F Quick Start Guide

57
Parameter
Name
Description
Setting Range
regulation (AVR)
1 : AVR is enabled
Range: 0, 1
Max.: 2
P3: Stall Prevention
P3-00
Stall Prevention
during
Acceleration
0 ∶ Disabled
1 ∶ Enabled the value set in P3-01.
Acceleration stops when the output current
exceeds the value set in P3-01. Acceleration
continues when the output current drops 15%
below the value set in P3-01.
Default: 1
Range: 0, 1
P3-01
Stall Prevention
Level during
Acceleration
Sets the output current level to activate the Stall
Prevention function during acceleration.
Default: 150%
Min.: 0%
Max.: 180
P3-02
Stall Prevention
Limit during
Acceleration
Sets the lower limit of Stall Prevention in the
constant power range as a percentage of the
drive rated output current.
Default: 50%
Min.: 0 %
Max.: 100 %
P3-03
Stall Prevention
during
Deceleration
0 : Disabled
The drive decelerates according to the set
deceleration time
1 : Enabled (Without Braking Resistor)
Default: 1
Range: 0, 1
P3-04
Stall Prevention
Level during
Deceleration
Sets the voltage level to activate the Stall
Prevention function during deceleration.
Default: 395V
Min.: 330V
Max.: 410V <3>
P3-05
Stall Prevention
during Run
0 : Disabled
1 : Enabled (Deceleration Time 1)
2 : Enabled (Deceleration Time 2)
Default: 1
Range: 0, 1, 2
P3-06
Stall Prevention
Level during Run
Sets the current level to activate the Stall
Prevention function during run.
Default: 150%
Min.: 30%
Max.: 180
P4: Frequency Detection
P4-00
Frequency
Detection Level
Sets the detection level and width for the multi-
function output terminal.
Default: 30.0 Hz
Min.: 0.0 Hz
Max.: <5>
P4-01
Frequency
Detection Width
Default: 2.0 Hz
Min.: 0.1 Hz
Max.: 25.5 Hz
P4-02
Frequency
Command Loss
Detection
Selection
Sets the drive operation when a frequency
command loss is detected.
0: Drive Stop
1: Continue operation according to the setting
Default: 0
Range: 0, 1
