LiteOn EVO600043S3D7E20F Quick Start Guide

58
Parameter
Name
Description
Setting Range
in P4-03.
P4-03
Frequency
Command at
Frequency
Command Loss
Sets the frequency command level at which the
drive runs when detecting a frequency
command loss and when L4-02 is set to 1. Sets
the value as a percentage of the maximum
output frequency set in d1-02.
Default: 80%
Min.: 0.0 %
Max.: 100.0 %
P4-04
Frequency
Command Loss
Detection Time
When the frequency command falls below 90% of
the command within this detection time, the
frequency command loss will be detected.
Default: 20ms
Min.: 20 ms
Max.: 400 ms
P5: Fault Restart
P5-00
Number of Auto
Restart Attempts
Sets the number of times to automatically
attempt to restart the drive when detecting GF,
OVA, OVD, OVC, OCA, OCD, OCC, OH, OL1, OL2,
OT1, OT2, PF and LF1.
Default: 0
Min.: 0
Max.: 10
P5-01
Auto Restart Fault
Output Operation
0 : Fault Output Disabled
1 : Fault Output Enabled
Default: 0
Range: 0, 1
P5-02
Fault Restart
Interval Time
Sets the amount of time between restart
attempts.
Default: 10.0 s
Min.: 0.5 s
Max.: 600.0 s
P6: Overtorque／Undertorque Detection
P6-00
Overtorque／
Undertorque
Detection
Selection 1
Sets the operation when the motor current
or torque exceeds the P6-01 level for longer
than the time set to P6-02.
0 : Disabled
1 : Overtorque Alarm at Speed Agree
2 : Overtorque Alarm at Run
3 : Overtorque Fault at Speed Agree
4 : Overtorque Fault at Run
5 : Undertorque Alarm at Speed Agree
6 : Undertorque Alarm at Run
7 : Undertorque Fault at Speed Agree
8 : Undertorque Fault at Run
Default: 0
Range: 0 to 8
P6-01
Overtorque／
Undertorque
Detection Level 1
Sets the level for overtorque/undertorque
detection 1.
Default: 150%
Min.: 0 %
Max.: 300 %
P6-02
Overtorque／
Undertorque
Detection Time 1
Sets the time for overtorque/undertorque
detection 1.
Default: 0.1 s
Min.: 0.0 s
Max.: 10.0 s
P7: Drive Protection
