LiteOn EVO600043S3D7E20F Quick Start Guide

61
Parameter
Name
Description
Setting Range
o4: Maintenance Settings
o4-00
Cumulative
Operation
Time Setting
Sets the initial value by 1 hours to start keeping
track of cumulative operation time.
Default: 0 h
Min.: 0
Max.: 9999
o4-06
U2 Reset Setting
Resets the data for U2-□□ (Fault Information) as
these data will not be reset by A1-03 (Reset).
0 ∶ Disabled
1 ∶ Enabled
Default: 0
Range: 0, 1
Group t, Auto-Tuning
t1: IM Motor Auto-Tuning
t1-01
Auto-Tuning Method
Selection
0 ∶ Rotational Auto-Tuning
1 ∶ Stationary Auto-Tuning
Default∶ 0
Range: 0, 1
t1-02
Motor Output
Power
Sets the motor rated output power in kW units.
Note: 1HP (Horse Power) = 0.746kW
Default∶ Determined
by o2-03
Min.: 0.00 kW
Max.: 650.00 kW
t1-03
Motor Rated
Voltage
Sets the motor rated voltage according to the
motor nameplate.
Default∶ 200.0 V
Min.: 0.0 V
Max.: 255.0 V <3>
t1-04
Motor Rated
Current
Sets the motor rated current according to the
motor nameplate.
Default∶ <2>
Min.: 10% of drive
rated current
Max.:200% of drive
rated current
t1-05
Motor Base
Frequency
Sets the motor base frequency according to the
motor nameplate.
Default∶ 50.0 Hz
Min.: 0.0 Hz
Max.: 400.0 Hz
t1-06
Number of Motor
Poles
Sets the number of motor poles according to
the motor nameplate.
Default∶ 4
Min.: 2
Max.: 48
t1-07
Motor Base Speed
Sets the motor base speed according to the
motor nameplate.
Default∶ 145 (x10 rpm)
Min.: 0 rpm
Max.: 2400 (x10 rpm)
t1-09
Motor No-Load
Sets the no-load current for the motor.
Default∶ o2-03

LiteOn EVO600043S3D7E20F Specifications

General

Brand	LiteOn
Model	EVO600043S3D7E20F
Category	Controller
Language	English
