Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Record Product’s Serial Number Here:
NOTE : If product has no serial number, record month and year of purchase instead.
NOTE :
Page 22
Part
Description Qty
1 14" Chain Guide Bar 1
2 14" Saw Chain 1
3 Chain Guide Bar Sheath 1
4 Screw 23
5 Washer 4
6 Chain Tension Knob 1
7 Lock Knob 1
8 Drive Cover 1
9 Circlip 1
10 Sealing Gasket 1
11 Non-Slip Washer 3
12 Bucking Spikes 1
13 Washer 4
14 Chain Tension Pin 1
15 Adjusting Screw Rod 1
16 Gear 1
17 Circlip 2
18 Pressure Plate 1
19 Sprocket 1
20 Knob Seat 1
21 Screw 4
22 Washer 1
23 Right Housing 1
24 Brake Spring 1
25 Left Winding Ring 1
26 Right Winding Ring 1
27 Screw 7
28 Screw 2
29 Connector 1
30 Clamp 1
31 Oil Tube Spring 2
32 Oil Tube 1
33 Circlip 1
34 Circlip 1
35 Bearing 2
36 Screw 4
37 Brake Housing 1
38 Output Shaft 1
39 Torsion Spring 1
40 Motor 1
Part
Description Qty
41 Microswitch 1
42 Worm Gear 1
43 Oil Pump 1
44 Pressure Plate 3
45 Left Housing 1
46 Rear Cover 1
47 Screw 5
48 Front Handle 1
49 Washer 1
50 Brake Pads 1
51 Hand Guard 1
52 Front Baffle Torsion Spring 1
53 Controller Assembly 1
54 Screw 1
55 Brake Connecting Rod 1
56 Brake Seat 1
57 Screw 4
58 Brake Pressure Plate 1
59 Sliding Block 1
60 Spring 3
61 Washer 1
62 Trigger 1
63 Lockout Switch 1
64 Sponge 1
65 Microswitch 1
66 Oil Tank 1
67 Dust-Proof Sponge 1
68 Air Valve 1
69 Anchor 1
70 Washer 1
71 Oil Tank Cap 1
72 Washer 1
73 Battery Pack 1
74 Plug-In Seat 1
75 Male Plug-In 3
76 Inner Wire 1
77 Hot Shrink Tube 4
78 Sponge 1
79 Oil Tube 1
80 Charger 1
Parts List and Diagram
Parts List
