MAGNET MAGIC!
Bits snap together with magnets. The
magnets are always right – you can’t
snap them together the wrong way.
C
ARROWS SHOULD POINT IN THE SAME DIRECTION
IF THE BITS WON’T SNAP TOGETHER, TRY SPINNING
ONE AROUND AND MAKE SURE THE ARROWS POINT
IN THE SAME DIRECTION
ORDER IS IMPORTANT
POWER BITS always come rst and
INPUT BITS only aect the OUTPUT
BITS that come after them.
D
WITH NO OUTPUT BIT AFTER IT, THE INPUT BIT HAS
NOWHERE TO SEND ITS SIGNAL
THE INPUT BIT AFFECTS THE OUTPUT BITS THAT FOLLOW
