Lkgps LK330 - Content Specifications; Userage; SIM Card Installation; Startup Procedure

4. Content Specs.
Content
Specs.
Dim.
120mm x 64mm x 35mm
Weight
250g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS chip
UBLOX
GPS sensitivity
-159dBm
GPS accuracy
10m
Time To First Fix
Cold status 35-80s
Warm status 35s
Hot status 1s
Battery
Un-chargeable 16000mAh
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +55°C
Humidity
5%--95% non-condensing
5.Userage:
5.1 SIM card installation
1.Open the rubber plug . 2.Insert the GSM SIM card. 3.close the rubber plug.
5.2Startup
 Put the SIM card and battery in place.
 Turn on the unit outdoors by Pushing the button to“On”the indicator is on.

Set admin number,APN , IP and open GPRS
Eg: Step1.admin123456+space+your phone number
Step2.apn123456+ space+local apn content
Step3.adminip123456+space+101.1.16.228+space+7700
Step4. gprs123456
 In 10 or 40 seconds, the unit will begin to work and acquire the GSM signals as well as the
