LMF Clima LCE - Page 21

firmware 2.4
Rev. 04
B
Valvola freddo +
Resistenza Post riscaldamento
Cooling valve + electric post heater
Kaltwasserventil +
ON-OFF Elektroheizer
Esterna
Immisione
Ripresa ambiente
Espulsione
Supply
Return
Fresh air
Exhaust
12
13
TH
1
2
230Vac
N= Neutro – Neutral - Neutral
Y1= Apre – Open - Öffnen
Y2= Chiude – Close - Schließen
N
Y2
Y1
7
6
3-POINT
230Vac
1
 (Password= 1)
  = 1
Serranda By-Pass (MBP)
By-Pass damper
Bypass-Klappe
1
2
4
5
230Vac
Pressostati filtri
Filter pressure switches
Druck verschmutzter filter
11
10
2
3
2
3
Sonda temp. mandata (BTM)
Supply air temperature sensor
Zuluft temperatur sensor
14
15
Esterna
Immisione
Ripresa ambiente
Espulsione
Supply
Return
Fresh air
Exhaust
Sonda temp. esterna (BTE)
Fresh air temperature sensor
Externer temperatur sensor
16
17
Esterna
Immisione
Ripresa ambiente
Espulsione
Supply
Return
Fresh air
Exhaust
OFF da remoto (On-Off)
Remote OFF
Remote OFF
8
9
Off
8
9
On
฀
