Load UP LB 3000 - Oil Refreshing Procedure; Application Range

26
REFRESHING THE OIL
1. Start the motor for several minutes and then stop the motor.
2. Remove the oil-level indicator.
3. Place the oil collect can under the motor, unscrew the oil drain plug and
drain the oil.
4. Replace the oil drain plug.
5. Fill with fresh oil up to the maximum level.
6. Replace the oil-level indicator.
8. APPLICATION RANGE
AC application
Model 75031/1 Power
factor
50 Hz
230 V
2300 W
1
50 Hz
230 V
1800 W
0,7~0,8
50 Hz
230 V
1600 - 2200 W
0,7~0,95
AC output
Unit 75031/1
Rated voltage V 230 V AC
Frequency Hz 50
AC current intensity A 10
Rated output VA 2300
Max. output VA 2800
DC tension V 12
DC current tensity A 8,3
