3
7000INST Copyright Lockmasters, Inc. 5/25/11
LKM7000 Front Plate Exploded View
Not all items are eld retro-ttable.
Component Part No.
Handle Screw 700012S13
Lock Washer for Handle Screw 700012S18
Intermediate Gear 700012S14
Hub Handle Half Gear 700012S01
Handle return Spring 700012S12
Outside Lever Handle 700012S11
Neoprene Handle Grip 7000HANDGRP
Complete Front Plate Assembly 700012WBA
