LockMaster LM138 - GENIE Garage Door Opener Connection Example

e.g. Connect the external receiver to GENIE garage door opener.
(a). Connect the black wire into “COMMON” terminal.
(b). Connect the brown wire into “PUSHBUTTON” terminal.
(c). Connect the red wire into “BEAM” terminal.
