Lockton ELEV36 - ELEV36 Box Contents; Included Parts Identification

Art. ELEV36
KEY PART QT Y.
a Front handle 1
b Front rubber
gasket
1
c Half euro cylinder 1
d C4 keys 2
e Cylinder screw 1
f Battery cover 1
g Rear handle 1
h Rear rubber
gasket
1
i Key fobs 2
j Screw-spindle
packs (see table)
4
k AAA Alkaline
Batteries
4
l Instruction Manual 1
m Template: Sliding 2
n Template: Hinged 2
Content of ELEV36 box
INSTRUCTIONS
SIEPER Group Tel: 02 9352 0600 E-mail: support@siepergroup.com www.sglocks.com.au
ELEV36 - SMART EURO MORTICE LOCK SLIDING - INSTALLATION TEMPLATE
Door Face
Handle Bottom
Door Face
*All Measurements in Millimetres
NOTE:
Handle Bottom
70mm
65mm
60mm
50mm
45mm
40mm
35mm
30mm
28mm
25mm
70mm
65mm
60mm
50mm
45mm
40mm
35mm
30mm
28mm
25mm
8.5
8.5
FOLD ON DESIRED BACKSET
FOLD ON DESIRED BACKSET
Arrow up
95
SIEPER Group Tel: 02 9352 0600 E-mail: support@siepergroup.com www.sglocks.com.au
ELEV36 - SMART EURO MORTICE LOCK SLIDING - INSTALLATION TEMPLATE
Door Face
Handle Bottom
Door Face
*All Measurements in Millimetres
NOTE:
Handle Bottom
70mm
65mm
60mm
50mm
45mm
40mm
35mm
30mm
28mm
25mm
70mm
65mm
60mm
50mm
45mm
40mm
35mm
30mm
28mm
25mm
8.5
8.5
FOLD ON DESIRED BACKSET
FOLD ON DESIRED BACKSET
Arrow up
95
32-38 mm 39-45 mm
46-52 mm
>53 mm
a b
c d e
f
g h
i
j
l
m n
1 2
3 4
k
