Loewe 34646 EBA WLAN - Page 27

27
Fig. 12
The rear panel of the TV set (e.g. as that of
the Individual 40 Selection LED 200 DR in the
example) is also secured by screws, indicated
AXSGD@QQNVRHMÅF
These screws must be removed.
Fig. 13
Remove the screws indicated by the arrows in
ÅFNMSGDQD@QRHCD
Fig. 14
Below this cover are two further screws that
require removal.
Detach the cover for easier access to the
screws.
(Open the cover and pull sideways towards
the rear)
Remove the screws indicated by the arrows.
