9
Front / Right Side View and Controls
Item Description
1 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate blue and then blink red and blue confirming that a timer
recording programme has started in the standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 Disc Slot
Insert the disc with the label side facing the rear of the TV. (12 cm discs only. Don't
insert 8 cm discs.)
4 Press to eject disc. (DVD mode)
5 Press to start playback or pause. (DVD mode)
6 SOURCE
Press to select among different input signal sources:
DTV / ATV / DVD / AV / SCART / YPBPR / HDMI 1 / HDMI 2 / HDMI 3 / PC / USB.
Confirmed the selection on OSD menu.
7 MENU Displays the OSD (on screen display) menu.
8 V + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
9 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
10 STANDBY Switches the TV on or into standby mode.
8
9
3
4
5
6
7
10
1 2
L32HED13_IB.indd 9 22/07/2013 12:48
