English - 10 -
on on the TV and the component video outputs of your device. While connecting, be sure
that the letters on your TV, “ Y ”, “ Pb ”, “ Pr ” correspond with your device’s connectors.
7. YPbPr Audio Inputs are used for connecting audio signals of a PC or a device that
connects to the TV via YPbPr.
Connect the PC audio cable between the AUDIO INPUTS on the TV and audio output of
your PC to enable PC audio.
Connect the audio cable between AUDIO INPUTS on the TV and audio outputs of your
device to enable component audio.
8. S/PDIF Coaxial Out outputs digital audio signals of the currently watched source.
Use an SPDIF coaxial cable to trasfer audio signals to a device that has S/PDIF input.
9. RF Input connects to an antenna or a cable.
Note that if you use a decoder or a media recorder, you should connect the aerial cable
through the device to the television with an appropriate antenna cable, as shown in the
illustrationin the following pages.
HDMI-2: 10.
HDMI Input
HDMI Inputs are for connecting a device that has an HDMI socket.
Your LCD Television is capable of displaying High Defi nition pictures from devices such as
a High Defi nition Satellite Receiver or DVD Player. These devices must be connected via
the HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i
signals. No sound connection is needed for an HDMI to HDMI connection.
HDMI 1: 11. HDMI Input
When you use the wall mount kit provided with the LCD TV, we would defi nitely recommend to
plug all your cables into the back of the LCD before mounting to the wall.
