9
INSTALLATION
water drain hose
U-shaped drain hose
holder
• You may use the U-shaped drain hose
holder to secure your drain hose and to
avoid bending it.
• Secure the water drain hose to the waste
pipe to avoid it coming off during the
washing process.
The waste pipe must only be connected
to the foul drains and not the surface
water drainage system.
The water drain hose should be placed
between 40 cm and 100 cm from the floor
level and must not be extended, otherwise
the unit may not be able to expel the
waste water properly.
LDW45S11_IB_110331.indd 9 3/31/11 5:04 PM
