INSTALLATION
6
2. Remove the 2 screws on the back.
3. Lift the top cover away from the fridge.
4. Remove the three screws, then remove
the upper hinge that holds the door in
place. Lift the upper door and place it
on a padded surface to prevent it from
scratching.
5. Swap the bottom bushing and bottom
bushing cap of the upper door. The
bottom bushing key must be in the
correct position to allow it to be inserted
correctly.
2. Remove the 2 screw covers first, then
undo the screws underneath.
To Next Page
