4. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
5. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
Unscrew
6. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
Unscrew
Screw
INSTALLATION
8
