Logitech Bluetooth Audio Adapter Complete Setup Guide

English 4
CONNECT THE RECEIVER TO YOUR SPEAKERS
AUX
RCA
1 2
A
B
Bluetooth
Logitech
BT Adapter
3 4 5
3. Press the Bluetooth pairing button on the Logitech Bluetooth Audio Receiver. It will initiate the pairing and the LED
willstart blinking (for rst time user, the pairing process will be initiated automatically).
4. Turn on Bluetoo th on your device and scan for Bluetooth devices. You will see “Logitech BT Adapter” on the device list.
Select and connect to it.
5. The LED will turn to a steady blue light. You can now play music through your audio device wirelessly.
6. To connect your second device, repeat step 3 through step 5.
1. Connect the power supply to the Logitech Bluetooth Audio Receiver. Then plug the power plug into an electrical outlet.
2A. If you have RCA input on your Speaker System:
- Connect RCA jack on the Speaker.
- Connect the other end of the cable to the Logitech Bluetooth Audio Receiver.
2B. If you have 3.5mm input on your Speaker System:
- Connect 3.5mm jack on the speaker.
- Connect the other end of the cable to the Logitech Bluetooth Audio Receiver.

Logitech Bluetooth Audio Adapter Specifications

General

Product color	Black
Internet radio services supported	-
Bluetooth	Yes
Ethernet LAN	No
Cables included	AC, Audio (3.5mm)
Master (outer) case width	123 mm
Master (outer) case height	174 mm
Master (outer) case length	223 mm
Master (outer) case weight	1400 g
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W

Weight and Dimensions

Width	500 mm
Height	230 mm
Package depth	110 mm
Package width	52 mm
Package height	150 mm
Package weight	175 g
