4 ENGLISH
INSTALLATION
1 DESK
1a. Place the wheel base on your desk and ensure the feet
atthe bottom are aligned against the edge.
1b. Insert the clamp into the hole at the front.
1c. Tighten the clamp by adjusting
the screw handle.
Once the clamp has come into contact with thedesk,
youonly need between a half and one full turn of
thehandle to achieve the correct level of clamping.
Donot overtighten.
< 50 mm (1.97 in)
1a
1b 1c
NOTE:
– Also be aware of the construction of your desk and
its suitability for clamping a high-torque wheel to it.
Somedesks use a hollow-core construction, for example,
where you have a top piece of material and a bottom
piece. Those pieces are likely to be thin and are unlikely
tostand up to the forces applied when the wheel is
clamped in place. Logitech recommends only clamping
your PRO Wheel to a desk made from a solid material,
suchas MDF or wood.
