5 ENGLISH
2 RACING SEAT
2a. Use the three bolt holes on the underside of the PRO
Racing wheel to attach it to most major racing seats.
– You will need 3 x M6X1 bolts (not included) with a
maximum depth inside the wheel base of 15mm.
Remember to account for the thickness of the surface
that you are attaching the wheel base to.
– Using a longer bolt than this will damage the wheel
unit, so use washers if needed to ensure that the bolts
do not encroach too far inside the wheel base.
– You only need to hand tighten. Do not use power tools
to tighten the bolts.
2b. You can use the included cover to ll the clamp hole
when attaching to a racing seat.
WARNING:
– Do not use the wheel rim as leverage to assist you when
getting into or out of your racing seat as this will damage
your PRO Racing Wheel.
M6X1
M6X1 L = T + 15MM
T L
2a
2b
