Logitech H820e

Logitech Wireless Headset Mono H820e/Dual H820e
4 English
Features
1. Volume up
2. Volume down
3. Call answer/end button
•LED lit when on a call
(supported by Microsoft Lync)
4. Battery icon
•Solid white: full charge
•Blinking white: charging
•Solid red: very low
5. Headset icon
•Blinking white: headset pairing
to base
•Solid white: headset paired to base
•Solid red: headset not paired to base
6. USB connection for PC
7. Wide Band/Narrow Band switch
•Default (WB)
•See Troubleshooting section
8. Power connection for wall power
9. Mute button
10. Mute LED
•Lit when microphone mute
2
4 5
9
7
6
8
3
1
10
CAUTION:
Please do not open.
No user serviceable parts.
