Logitech H820e User Manual

Logitech Wireless Headset Mono H820e/Dual H820e
English 5
USB
1
2
1. Connect the base to power using the Class 2 power
source provided.
2. Connect the base to the PC using the USB connection.
3. Use only adaptor supplied by Logitech, model list:
– KSAS0060510100D5D, 5.1VDC, 1A
– AD631MC, 5.15VDC, 1A
4. The equipment is to be supplied from an identified
USB port complying with the requirements of Limited
Power Source.
For charging, the Headset must sit on the base charger
between the Ear Cup and Headband. The battery icon (4)
will be lit when connected properly.
Please use only with Class 2 power source.

Logitech H820e Specifications

General

Headset type	Binaural
Product type	Headset
Product color	Black
Wearing style	Head-band
DECT connectable	Yes
Recommended usage	Office/Call center
Sound pressure level (max)	100 dB
Quantity	1
Cables included	USB
Wireless range	100 m
Connectivity technology	Wireless
Ear coupling	Supraaural
Headphone frequency	150 - 7000 Hz
Headphone sensitivity	103 dB
Total Harmonic Distortion (THD)	4 %
Microphone type	Boom
Microphone frequency	100 - 7000 Hz
Microphone sensitivity	-45 dB
Microphone direction type	Bidirectional microphone
Distortion	10 %
Input voltage	1.4 - 5 V
Battery weight	9 g
Other operating systems supported	Linux
Master (outer) case width	190 mm
Master (outer) case height	490 mm
Master (outer) case length	250 mm
Master (outer) case weight	4000 g
Harmonized System (HS) code	85183000
Package depth	236 mm
Package width	180 mm
Package height	79 mm
Package weight	250 g
Battery type	Built-in battery
Battery capacity	430 mAh
Continuous audio playback time	10 h
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1, Windows Vista

Weight and Dimensions

Depth	50 mm
Width	174 mm
Height	165 mm
Weight	128 g
