Logitech RALLY MIC POD User Manual

13
RALLY MIC POD PLACEMENT GUIDE
RALLY PLUS
Designed for greater exibility in larger rooms, Rally Plus supports up to seven mic pods and seven mic pod hubs.
As Rally Plus uses only external mic pods, their placement replicates what’s described above with Rally Bar and
Rally Bar Mini in Speaker Boost Mode. Again, mic pods should be spaced a maximum of 8 ft (2.4 m) apart and
consideration should be given to where people will be in the room, either at the conference table or also seated
along the walls.
With up to seven mic pods, a variety of larger congurations can be supported, such as large U-shaped tables:

Logitech RALLY MIC POD Specifications

General

Connection Type	Wired
AEC	Yes
VAD	Yes
Noise Suppression	Yes
Pickup Pattern	Omnidirectional
Compatibility	Logitech Rally System
Microphone Elements	eight omnidirectional microphones
Pickup Range	Up to 4.5 meters diameter
Cable Length	3 m (9.8 feet)
