RALLY MIC POD PLACEMENT GUIDE
TYPICAL MIC POD CONFIGURATIONS
This section provides examples of mic pod placement when using a Rally conference camera in a default setup—
without Speaker Boost Mode.
In the default setup, both external mic pods and internal mics are active. The internal mics pick up voices closer
to the video bar, while the external mic pods pick up voices that are farther away.
The diagram below is the most basic conguration for expanding the mic pickup range. The rst mic pod should
be mounted 12’ (3.7 m) from the video bar to ensure sucient mic pod range overlap. Each mic pod has a
pickup range of 15’ (4.6 m) diameter.
