Connect the cables
Setup with TV and set-top box (STB) Setup with TV, STB, and Audio-video receiver (AVR)
1
Tip: Write down the make and model
numbers of your TV, STB and AVR, and note
the input port Revue uses for each one.
You’ll need this information for setup.
1 If your AVR has no HDMI ports, use the SPDIF
port to connect your AVR to Revue. Do not
connect the AVR to the TV.
2 Revue works with either wired or wireless
Internet. When using Wi-Fi, the Ethernet cable
is not required.
Ethernet
(optional)
2
Ethernet
(optional)
2
Power source Power source
HDMI In HDMI InHDMI Out HDMI Out
AVR
TV TV
Internet
modem
Internet
modem
STB STB
1
