Español 13
Acerca del sistema de altavoces Z-540 de Logitech
®
¡Enhorabuena por la compra del sistema de altavoces Z-540 de Logitech
®
! Su sonido superior
le sorprenderá gratamente, con una mejora de la experiencia de audio en el PC. Para obtener
más información sobre productos Logitech
®
, visite nuestra página Web: www.logitech.com.
- +
SUB
VOLUME
FRONT RIGHT
volume
fader
m3d
power
5
6
D
C
B
A
3
4
1 287
1. Subwoofer
2. Altavoz frontal izquierdo:
conector amarillo
3. Altavoz posterior izquierdo:
conector blanco
4. Cable de alimentación
5. Altavoz posterior derecho –
conector rojo
6. Cable de entrada de audio a PC:
conectores negro y verde
7. Altavoz frontal derecho
8. Volumen del subwoofer
A. M3D
B. Equilibrio frontal/posterior
C. Control de encendido
D.Volumen del sistema
