Inputs/Outputs
SoundTouch™ Digital Control Center inputs:
• (2) Digital S/PDIF optical connection: For DVD or CD players, PlayStation®2, Xbox™*, or PC sound cards
(requires optical cable, sold separately): black Toslink jack
• (1) Digital S/PDIF coax connection: For DVD or CD players or PC sound cards (requires coaxial cable,
sold separately): black RCA jack
• (1) 6 channel direct (3 stereo-mini 3.5mm stereo jacks w/green (front satellite inputs), black (rear
satellite inputs), and orange (subwoofer and center channel inputs)): For 2, 4, or 6 channel PC sound
card analog connections
OR
• (3) Stereo inputs (3 stereo-mini 3.5mm stereo jacks w/green (Stereo 1 input), black (Stereo 2 input),
and orange (Stereo 3 input)): For 3 stereo-mini analog audio sources, like CD and DVD players,
PlayStation®2, Xbox™, or 2 channel PC sound cards (some devices may require stereo-mini to dual RCA
adapter, sold separately)
• (1) Analog stereo-mini (on side panel of control pod): For portable CD, MP3, or MiniDisc® players
• 2-position switch (near analog jacks): Switch between ‘6 ch direct’ and ‘stereo 1-3’ modes
Digital LCD
While in the Ready state, the first line of the LCD displays the current source input. The second line displays
the current surround sound effect.
9 kHz / bit bitstream
DTS® Digital Surround delivers 5.1 digital sound that rivals master soundtracks. DTS® soundtracks are included
in many DVD videos, DVD Audio discs and PlayStation®2 games. The Z-5450 Digital includes a hardware DTS®
decoder for master quality sound. The Z-5450 Digital also includes support for DTS® 96/24 - an enhanced,
higher-resolution, studio-quality format available on many DVD video and DVD Audio discs.
For wireless transmission to the rear channels, Logitech introduces the world’s first THX®-certified wireless
rear speaker system that features independent rear channels (no wires between rear speakers or a receiver
box). This proprietary digital wireless technology offers state of the art clarity and reliability with adaptive
channel hopping, redundant transmission of music streams, and low latency using 48kHz sample rates.
96kHz audio streams are re-sampled to 48kHz in the rear channels only.
Selecting Your Source Input
Pressing the Input button cycles through the various audio input sources.
The inputs will always cycle in the same order, as shown below.
With -position Switch in ‘ Ch. Direct’ Mode:
• Direct: input stream from the analog inputs
• Optical 1: input stream from the Optical 1 input
• Optical 2: input stream from the Optical 2 input
• Coax: input stream from the coax input
Cycling through the inputs is always the same unless you have the 2-position switched to ‘Stereo 1-3’ mode.
With -position Switch in ‘Stereo -’ Mode:
• Stereo 1: Use the Front L/R analog input (green) as a stereo input
• Stereo 2: Use the Rear L/R analog input (black) as a stereo input
• Stereo 3: Use the Center/Sub analog input (orange) as a stereo input
• Optical 1: input stream from the Optical 1 input
• Optical 2: input stream from the Optical 2 input
• Coax: input stream from the coax input
