Headphones
When the headphones are plugged in, the speakers will mute and all sound will go to the headphones. The
LCD will display ‘Headphones’ as the active effect. Only a stereo signal will go the headphones, regardless of
the input or surround sound effect. When listening to material with surround sound content, the audio will be
“downmixed” so that all the sounds are heard in the headphones. When the headphones are unplugged, the
speakers will automatically return to their previous state.
Wall-Mounting
There is 1 slot on the underside of the Satellite Speaker that can be used for wall mounting.
When wall mounting the unit, ensure that it is within reach of the power outlet.
You will need 1 screw (4.4 mm) to wall mount the unit. To do this:
1. Ensure that the wall you use is smooth, at, dry and sturdy.
2. Fix the screws into the wall, leaving their heads 3 mm (0.12 in.) clear of the wall surface.
3. Remove any connections to the unit and locate it over the screw heads. When in line, gently push the
unit on to the wall and move it downwards to secure.
Muting the Speakers
To mute the speakers, simply press the mute button. The speakers will be muted and the control pod LCD will
display ‘Mute On’. The speakers will remain muted until any of the following occur:
• ‘Standby’ button is pressed. Speakers go into standby mode.
• ‘Mute’ button is pressed again. The speaker volume returns to previous volume level and speakers go to
Ready state.
• ‘Level’, ‘input’, ‘effect’, or ‘settings’ button is pressed. The speaker volume returns to the previous level
and the product performs the appropriate action for the button that was pressed.
• Control knob is rotated (disengages mute and adjusts Main volume).
• ‘TEST’ button is pressed on the remote (puts system in Test Mode).
Changing Surround Sound Settings
To change the surround sound settings, press the ‘settings’ button. Not all settings are available for each
effect (see table below). If the active effect does not have changeable settings, then the LCD will show
‘No settings for this effect’.
Cables
• Satellites:
– L / R cord length: 15’ (4.5m)
– C cord length: 15’ (4.5m)
• Cables:
– 8’ 3-pair cable with (3) 3.5mm male stereo connectors on each end – color-coded to match the
jacks on the control pod
• Subwoofer:
– Control pod connection: Female D-SuB jack
– Powered connections to front/center satellites: spring clips
• Subwoofer connection: 8’ D-SuB cable
•
•
•
• • • •
•
