Logosol B1001 - Assembly; Assembly Steps 1-3

10
ASSEMBLY
Fit the XL log clamp holder to the original cross
bunk. Make sure that the log clamp holder is
installed with the square hole on the same side of
the rail frame as the original log support. Use the
existing bolts for the assembly.
1
2
3
2x 03-02650
3x M 8 x 14
3x M 8 x 14
3x M 8
3x M 8
2x 12x60
2x 3.2 x 25
