13
LOG HANDLING
ASSEMBLY
Mount the new anti-tip rails. Use the original bolts
that hold the rails. Start and nish the assembly
with the “end pieces”. Be careful not to unscrew
the bolts too much, since this can make the nuts
fall off.
Fit the anti-tip wheels to the anti-tip plate. Use
the washers and the nuts from the existing
assembly.
8
9
10
2x M 6 x 35
2x M 10 x 95
4x M 10
