LOGSMITH BM11126 - Specifications; Assembly

Page 6
6SHFL¿FDWLRQV
Fuel
Type
87+ octane unleaded
gasoline
Capacity 1 Gallon
Coolant Tank Capacity 4.2 Quarts
Blade Speed 3,279 FPM
Log Diameter Ǝ0D[LPXP
Board Width Ǝ0D[LPXP
Cutting Thickness Ǝ0D[LPXP
Cutting Length ƍƎ0D[LPXPƎ
Note: (QJLQHVSHFL¿FDWLRQVDUHIRXQGLQWKH
engine manual supplied with this equipment.
Assembly
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual
including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY:
Operate only with proper spark arrestor installed. Operation of this equipment may create sparks that can
VWDUW¿UHVDURXQGGU\YHJHWDWLRQ$VSDUNDUUHVWRUPD\EHUHTXLUHG
7KHRSHUDWRUVKRXOGFRQWDFWORFDO¿UHDJHQFLHVIRUODZVRU
UHJXODWLRQVUHODWLQJWR¿UHSUHYHQWLRQUHTXLUHPHQWV
TO PREVENT SERIOUS INJURY: The Saw Mill is dangerous when assembled incorrectly.
,I\RXGRQRWIHHOFRPSOHWHO\FRPIRUWDEOHDVVHPEOLQJLWWKHQKDYHDTXDOL¿HGWHFKQLFLDQDVVHPEOHLW
Note: For additional information regarding
the parts listed, refer to Assembly Diagram
near the end of this manual.
1. Secure Wheels (1) onto Right Wheel Frame (7a)
with two Hex Bolts M20x100 (6) and Hex Nuts
M20 (2). Attach Right Wheel Frame, Round
Post (20) and the Round Clamp (10) with two
Hex Bolts M12x80 (8) and Hex Nuts M12 (9).
Note: Do not tighten Bolts (8) and Nuts (9).
1
7a
6, 2
20
10
8, 9
Figure A: Right Wheel Frame
2. Secure Wheels (1) onto Left Wheel Frame (3a)
with two Hex Bolts M20x100 (6) and Hex
Nuts M20 (2). Then attach Left Wheel Frame,
Square Post (48) and Square Clamp (4)
with two Hex Bolts (58) and Hex Nuts (5).
Note: Do not tighten Bolts (58) and Nuts (5).
Figure B: Left Wheel Frame
1
3a
6, 2
48
4
58, 5
3. Slide the Round Post (20) into the Blade Guard (50),
as shown below. Adjust the bolts until Blade Guard
SAFETY OPERATION MAINTENANCEASSEMBLY
