ii. Status adjustment of the tiller
1. Adjustment of handle frame
Note: Before adjusting height of handle frame, please put the machine on a flat horizontal ground to
prevent it from accidental falling.
● Loosen the lifting handle and select the hole in an appropriate position, then adjust the handle’s
cross bar to as high as user’s waist, then turn the lifting handle to tighten it (See Fig. 5).
2. Adjustment of tilling depth
● By adjusting height of damping lever, tilling depth can be adjusted. Specifically, adjusting the
lever downward will increase tilling depth, and adjusting it upward will decrease tilling depth. (See Fig.6)
3. Adjustment and use of clutch
Note: Before using the clutch, lower the engine speed.
● By “engage ” and “disengage ”of the clutch, the user can
control output of engine’s power.
● When the user holds tight the clutch lever, the clutch is engaged
and transmits engine power to the tiller and tilling blades begin to
rotate. (See Fig.7)
Figure 6
To Next Page
