Loop Telecom Loop-O9500R - Page 12

Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
12
For 4E1 and 3E1 card:
 Where cc is used to select connector:
cc =
Description
Notes
RJ
RJ48C connector
BNC
BNC connector
For 8UDTEA card:
 Where opm is used to select 8UDTEA functions:
opm =
Description
DCE
Support RS232/RS422/RS485 DCE interface which is software configurable
TS
Support Terminal Server Function and DCE
OMNI
Support Omnibus Function and DCE
CPT
Support Clock Pass Through function and DCE
TSOMNI
Support Terminal Server, Omnibus Function and DCE
HD
Support RS232/RS422/RS485 DCE interface with Full- and Half-Duplex modes
TSHD
Support Terminal Server Function and DCE with Full- and Half-Duplex modes
OMNIHD
Support Omnibus Function and DCE with Full- and Half-Duplex modes
TSOMNIHD
Support Terminal Server, Omnibus Function and DCE with Full- and Half-Duplex
modes
Feature Activation License
Description
Loop-AM3440-8UDTEA-UPGR-TS
Feature Activation License for AM3440 8UDTE card to support Terminal Server
function
Loop-AM3440-8UDTEA-UPGR- OMNI
Feature Activation License for AM3440 8UDTE card to support Omnibus function
Loop-AM3440-8UDTEA-UPGR-CPT
Feature Activation License for AM3440 8UDTE card to support Clock Pass
Through function
Loop-AM3440-8UDTEA-UPGR-TSOM
NI
Feature Activation License for AM3440 8UDTE card to support Terminal Server
function and Omnibus function
Loop-AM3440-8UDTEA-UPGR-HD
Feature Activation License for AM3440 8UDTE card to support Full- and
Half-Duplex modes
Loop-AM3440-8UDTEA-UPGR-TSHD
Feature Activation License for AM3440 8UDTE card to support Terminal Server
function with Full- and Half-Duplex modes
Loop-AM3440-8UDTEA-UPGR-OMNI
HD
Feature Activation License for AM3440 8UDTE card to support Omnibus function
with Full- and Half-Duplex modes
Loop-AM3440-8UDTEA-UPGR-TSOM
NIHD
Feature Activation License for AM3440 8UDTE card to support Terminal Server
function and Omnibus function with Full- and Half-Duplex modes
For 1FOMB Card:
 where opt is used to select optical module type:
opt =
Description
Notes
SAA
single optical module with dual uni-directional fiber, 1310 nm,
SC optical connector, 30 km- S1.1 physical layer*
 Use 2 fibers
 * ITU-T Rec G.957 application
code
SBB
single optical module with dual uni-directional fiber, 1310 nm,
SC optical connector, 50 km - L1.1 physical layer*
SCC
single optical module with dual uni-directional fiber, 1310 nm,
FC optical connector, 30 km - S1.1 physical layer*
SDD
single optical module with dual uni-directional fiber, 1550 nm,
SC optical connector, 20 km - S1.2 physical layer*
SEE
single optical module with dual uni-directional fiber, 1550 nm,
SC optical connector, 100 km - L1.2 physical layer*
SSM
single optical module with single bi-directional fiber (master),
1310 nm transmit and 1550 receive, SC optical connector,
30 km reach - S1.1/ S1.2 physical layer*
 1310 nm from master to slave
 Order SSM to use with SSS
 Use 1 fiber
 * ITU-T Rec G.957 application
code
SSS
single optical module with single bi-directional fiber (slave),
1310 nm receive and 1550 transmit, SC optical connector,
30 km reach - S1.1/ S1.2 physical layer*
 1550 nm from slave to master
 Order SSS to use with SSM
 Use 1 fiber
 * ITU-T Rec G.957 application
code
NOTE: For other special optical modules, please contact your nearest Loop sales representative.
