Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
11
Y-box Panels for 75 ohm
Y-Box
(75 ohm)
E1 (120 ohm)
(SCSI)
E1 (120 ohm)
(SCSI)
E1 (75 ohm)
(TELCO 50, or TELCO 64)
Loop-ACC-Y-2SCSI-
2T50P8-16E75-G
1u 16-port Y-box panel for two SCSI (E1(120
ohm)) to two TELCO 50 (E1(75 ohm))
connectors (8 ports per TELCO connector)
without cable
Use with Loop-O9500-R-16TE-G
Loop-ACC-Y-2SCSI-
2T50P12-16E75-G
1u 16-port Y-box panel for two SCSI (E1(120
ohm)) to two TELCO 50 (E1(75
ohm))connectors (12 ports to the first TELCO
connector, 4 ports to the second TELCO)
straight without cable
Use with Loop-O9500-R-32TE-G or
Loop-O9500-R-63TE-G
Loop-ACC-Y-2SCSI-
1T64P16-16E75-G
1u 16-port Y-box panel for two SCSI (E1(120
ohm)) to one TELCO 64 (E1(75
ohm))connectors (16 ports per TELCO
connector) straight without cable
Use with Loop-O9500-R-16TE-G
Loop-ACC-Y-4SCSI-
4T50P8-32E75-G
1u 32-port Y-box panel for four SCSI (E1(120
ohm)) to four TELCO 50 (E1(75
ohm))connectors (8 ports per TELCO
connector) without cable
Use with Loop-O9500-R-16TE-G
Loop-ACC-Y-4SCSI-
3T50P12-32E75-G
1u 32-port Y-box panel for four SCSI (E1(120
ohm)) to three TELCO 50 (E1(75
ohm))connectors (12 ports to the first TELCO
connector, 12 ports to the second TELCO
connector and 8 ports to the third TELCO
connector) without cable
Use with Loop-O9500-R-32TE-G or
Loop-O9500-R-63TE-G
Loop-ACC-Y-4SCSI-
2T64P16-32E75-G
1u 32-port Y-box panel for four SCSI(E1(120
ohm)) to two TELCO 64 (E1(75
ohm))connectors (16 ports per TELCO
connector) without cable
Use with Loop-O9500-R-32TE-G or
Loop-O9500-R-63TE-G
Y-Box (All Y-Box are RoHS compliant)
Loop-VV-B-G
1 for 1 protection Y-Box with BNC connectors
(4-E1)
Use with Loop-O9500-R-4E1-BNC-G
Loop-VV-R-G
1 for 1 protection Y-Box with RJ48C connectors
(16-E1)
Use with Loop-O9500-R-4E1-RJ-G
Loop-VV-T-G
1 for 1 protection Y-Box with RJ48C connectors
(16-T1)
Use with Loop-O9500-R-4T1-G
Conversion Cables (All conversion cables are RoHS compliant)
Loop-ACC-CAB-SCSI68M-200-
1SCSI68M-G
SCSI 68 pin/Male to SCSI 68 pin/Male
Extension Cable Length:200cm
Used in Loop-O9500-R Y-box panels and
conversion panels
Loop-ACC-CAB-DB44M-
100-2DB25F-1DB09F-DB
DSUB-44 pin/Male to two DSUB-25
pin/Female- one DSBU-9 pin/Female
Length 100cm
Used in Loop-O9500-R-8RS232-DB-G
Loop-O9500-R-8DBRA-DB-G plug-in card
Loop-ACC-CAB-DB25M-30-1M
34F
DSUB-25pin/Male to M34/Female V.35
Conversion cable
Length: 30 cm
Used in Loop-O9500-R-6V35A-G plug-in
card
Loop-ACC-CAB-DB25M-30-1D
B37F
DSUB-25pin/Male to DSUB-37/Female
RS449 Conversion cable Length: 30 cm
Used in Loop-O9500-R-6V36A-G and
Loop-O9500-R-6R449A-G plug-in cards
Blank Panels
30.001397.A00LF
Blank panel for CPU slot
30.001076.A00LF
Blank panel for power supply slots
Same as that used on O9400R.
30.001077.A00LF
Blank panel for High-speed slots (Slots 1~4)
Same as that used on O9400R.
30.001027.A00LF
Blank Panel for Low-speed slots (Slots
11~16)
Same as that used on AM3440-A.
