Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
17
Line Rate
1.544 Mbps  32 ppm
Framing
D4/ESF
Line Code
AMI/B8ZS
Output Signal
DSX-1 w/0, -7.5, -15 dB LBO
Input Signal
DSX-1 0dB to -30dB w/ALBO
Connector
RJ48C
Jitter
AT&T TR 62411
Pulse Template
AT&T TR 62411
Data Rate
n * (64) Kbps (n = 1 to 24)
Surge Protection
FCC Part 68 Sub Part D
G.shdsl Line Interface (2GH/4GH)
Number of ports
2 or 4
Line Rate for 4-channel G.shdsl
n x 64Kbps (n= 3 to 31)
Line Rate for 2-channel G.shdsl
n x 64Kbps (n= 3 to 15)
Line Code
16-TCPAM, full duplex with adaptive echo cancellation
Connector
RJ45
Electrical
Unconditioned 19-26 AWG twisted pair
Sealing current
Max. 20 MA source current
Clock Source
From System, Line
Diagnostic Test
G.SHDSL Loopback: To-LINE, To-bus
BERT: QRSS
DTE(X.21/V.11) Interface (6X21A)
Data Port
Up to six 6-port DTE X.21 card; 1-port DTE X.21 card
Data Rate
56 or 64 Kbps, n = 1 to 32
Connector
DB15
DTE (V.35/ V.36) Interface (6V35A/6V36A)
Data Port
Up to six 6-port DTE V.35/ V.36 cards
Data Rate
56 or 64 Kbps, n = 1 to 32
Connector
For V.35 card: DB25S (optional conversion cable DB25S to M34 connector)
For V.36 card::DB25S (optional conversion cable DB25S to DB37 connector)
DTE (EIA530/RS449) Interface (6 EIA530A/6RS449A)
Data Port
Up to six 6-port EIA530 DTE card
Data Rate
56 or 64 Kbps, n = 1 to 32
Connector
DB25S (optional conversion cable DB25S male to DB37 female connector for RS449)
C37.94 Interface (1/4C37)
Source
LED
Wavelength
820nm 2Km reach
Connector
ST
Optical Budget
50 Mircon core/9.6 db
62.5 Mircon core/ 15db
Dry Contact I/O card (8DC)
Inputs -
Outputs -
8-channel
2-port per card, 4-pair per port
8-channel
8-pair per card
Connector
RJ45
Connector
Screw type
Internal Resistance
1 K
Initial Insulation Resistance
Min. 100M ohm (at 500 Vdc)
Activation Current
3 ma
Max. Current
5A
Deactivation Current
1.5 ma
Max. Voltage
100 Vdc, 250 Vac
Allowable Current
4 ma
Dry Contact Type B Interface
Inputs -
Outputs -
8-channel
2-port per card, 4-pair per port
8-channel
8-pair per card
Connector
RJ45
Connector
Screw type
Internal Resistance
100 K
Initial Insulation Resistance
Min. 1000M ohm (at 500 Vdc)
Activation Current
3 ma
Max. Current
2A
Deactivation Current
1.5 ma
Max. Voltage
220 Vdc, 250 Vac
Allowable Current
4 ma
Co-directional (G.703) card
Interface
ITU G.703 64 Kbps co-directional interface
Connector
120ohm, RJ48
Line Distance
Up to 500 meters
Loopback
DTE Payload Loopback, Local Loopback
Router-B Interface (RTB)
Number of ports
8 LAN ports, Max. 64 WAN ports. Each WAN port has data rate n x 64K bps, 1 n 32
( 8Mbps for total of all 64 WAN ports
