Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
16
Fast Ethernet interface
Line Rate
10/100M bps
Mapping
n x VC12, n x VC3, or n x VC4
Layer2 Protocol
RSTP (802.1W),
Connector
RJ45
VLAN (802.1Q, 802.1P)
Flow Control (802.3X)
MSTP (802.1S)
IGMP Snooping
QoS
Prrocess Protocol
VCAT, GFP(G.7041), LAPS,
LCAS(G.7042), and non-LCAS
Gigabit Ethernet interface
Line Rate
10/100/1000Mbps
Mapping
n x VC12, n x VC3, or n x VC4
Layer2 Protocol
RSTP (802.1W),
Connector
RJ45
VLAN (802.1Q, 802.1P)
Flow Control (802.3X)
MSTP (802.1S)
IGMP Snooping
QoS
Process Protocol
VCAT, GFP(G.7041), LAPS,
LCAS(G.7042), and non-LCAS
7 FOM
Port number
7
Source
Laser
Line Code
Scrambled NRZ
Wavelength
1310  50 nm, 1550  40 nm
Optical Line Rate
38.84Mbps
Connector
SFP housing with LC type
Reach
2~240 Km
(For more detail, please refer to the SFP table
below)
Protection
1+1 Line Protection
1FOMB
Source
MLM Laser
Line Code
Scrambled NRZ
Wavelength
1310  50 nm, 1550  40 nm
Detector Type
PIN-FET
50 Km reach
NOTE: Longer or shorter, 15 to 120Km, on special order.
Diagnostics Test
Optical Fiber
Local and remote loopbacks
E1 Link
Local and remote loopback, send test pattern
Low Speed Tributary Modules
Network Line Interface – 4E1
Line Rate
2.048 Mbps  50 ppm
Framing
ITU G.704
Line Code
AMI or HDB3
Connector
BNC/RJ48C
Input Signal
ITU G.703
Electrical
75 ohm Coax/120 ohm twisted pair
Output Signal
ITU G.703
Jitter
ITU G.823
Network Line Interface - 4T1
Line Rate
1.544 Mbps  32 ppm
Output Signal
DSX1w/0, -7.5, -15 dB LBO
Line Code
AMI or B8ZS
Framing
D4/ESF (selectable)
Input Signal
DSX-1 0 dB to -30 dB w/ALBO
Connector
RJ48C
Network Line Interface - 3E1
Line Rate
2.048 Mbps  50 ppm
Framing
ITU G.704
Line Code
AMI or HDB3
Connector
BNC/RJ48C
Input Signal
ITU G.703
Electrical
75 ohm Coax/120 ohm twisted pair
Output Signal
ITU G.703
Jitter
ITU G.823
Function
Support DS0-SNCP
Network Line Interface – 3T1
