Loop-O9500R SDH/SONET IMAP Product Specification
High Speed or High Density Tributary Modules
Max. Number of Aggregate Lines on Controller Modules
4 STM-1/4 (OC-3/12) aggregate optical lines or
4 STM-1/4/16 (OC-3/12/48) aggregate optical lines (CC16)
Max. Number of HS Tributary Lines for CC4 Controller Module
1 STM-4 (OC-12) tributaries without protection
6 STM-1 (OC3) tributaries without protection
12 E3/T3 tributaries without protection
252 E1/T1 tributaries without protection
4 GbE +32 FE EoS with build in L2 switch tributaries without protection
4 GbE or 32 FE EoS without build in L2 switch tributaries without protection
28 FOM tributaries without protection
Max. Number of HS Tributary Lines for CC16 Controller Module
4 STM-4 (OC-12) tributaries without protection
8 STM-1 (OC3) tributaries without protection
12 E3/T3 tributaries without protection
252 E1/T1 tributaries without protection
4 GbE +32 FE EoS with build in L2 switch tributaries without protection
4 GbE or 32 FE EoS without build in L2 switch tributaries without protection
8 GbE EoS with build in L2 switch tributaries without protection with backplane capacity up to 2.5G
28 FOM tributaries without protection
T1 Interface
Line Rate
1.544 Mbps  32 ppm
Jitter
ITU G.824
Line Code
AMI/B8ZS
Framing
Unframed with a framing monitor on
receiving side
Input Signal
ITU G.703 DSX-1 0dB to –6dB
Impedance
100 ohm twisted pair
Output
Signal
ITU G.703 DSX-1 w/short (0-110, 110-220,
220-330, 330-440, 440-550, 550~660 (feet)
Connector
SCSI-II 68-pin
One connector for 16 ports
Two connectors for 32 ports
Four connectors for 63 ports
Output
Mask
Bellcore GR-499-core
E1 Interface
Line Rate
2.048 Mbps  50 ppm
Jitter
ITU G.823
Line Code
AMI/HDB3
Framing
Unframed with a framing monitor
on receiving side
Input Signal
ITU G.703
Impedance
75 ohm coax/120 twisted pair
Output Signal
ITU G.703
Connector
SCSI-II 68-pin
One connector for 16 ports
Two connectors for 32 ports
Four connectors for 63 ports
Output Mask
ETS 300 689 Sec.4.2.1.2 ITU G.703
E3 Interface
Line Rate
34.368 Mbps ± 20ppm
Jitter
ITU G.823
Line Code
HDB3
Framing
Unframed, G.751
Input Signal
ITU G.703
Impedance
75 ohm coax
Output Signal
ITU G.703
Connector
BNC connector
Output Mask
ETS 300 689 Sec.4.2.1.2 ITU G.703
T3 interface
Line Rate
44.736 Mbps ± 20ppm
Jitter
ITU G.824
Line Code
B3ZS
Framing
Unframed, M13/Mx3 (unframed
E1/T1), G.747
Input Signal
ITU G.703
Impedance
75 coax
Output Signal
ITU G.703
Connector
BNC connector
Output Mask
Bellcore GR-499-core
