Loop Telecom Loop-O9500R - Page 26

Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
26
Front Panel View of O9500R with CC4 Controller on CHA Chassis
O9500R Hardware Configuration Chart on High Speed Slot and CPU
High Speed Tributary Cards Without Protection (with CC4 Controller)
Plug-in Card
Slot
E1/T1
E3/T3
7FOM
9EoS4SW
Optical (SFP)
FE
GbE
STM-1/OC-3
STM-4/OC12
H
S
TRIB 1
63/32/16
3
7
8
1
2
1
Note 2
TRIB 2
63/32/16
3
7
8
1
2
TRIB 3
63/32/16
3
7
8
1
1
X
TRIB 4
63/32/16
3
7
8
1
1
X
XCU 1
X
X
X
X
X
2
2
XCU 2
X
X
X
X
X
2
2
Maximum Port
of Each Interface
252
12
28
32
4
10
5
High Speed Tributary Cards With Protection (with CC4 Controller)
Plug-in Card
Slot
E1/T1
E3/T3
7FOM
9EoS4SW
Optical (SFP)
FE
GbE
STM-1/OC-3
STM-4/OC12
H
S
TRIB 1
63/32/16
3
7
8
1
2
1
TRIB 2
63/32/16 (B)
3(B)
7 (B)
8 (B)
1 (B)
2 (B)
1 (B)
TRIB 3
63/32/16
3
7
8
1
2
X
TRIB 4
63/32/16 (B)
3(B)
7 (B)
8 (B)
1 (B)
2 (B)
X
XCU 1
X
X
X
X
X
2
2
XCU 2
X
X
X
X
X
2 (B)
2 (B)
Maximum Port
of Each Interface
126
6
14
16
2
6
3
(B) backup/protection
Note 2: To set up STM-4/OC12 without protection, put only one optical-module-with-protection in either TRIB 1 or TRIB2 slot.
