Loop Telecom Loop-O9500R - Page 27

Loop-O9500 SDH/SONET IMAP
SDH/SONET-MSTP
27
Front Panel View of O9500R with CC16 Controller on CHAA Chassis
High Speed Tributary Cards Without Protection (with CC16 Controller)
Plug-in Card
Slot
E1/T1
E3/T3
7FOM
9EoS4SW
4GESW*
Optical (SFP)
FE
GbE
GbE
STM-1/
OC-3
STM-4/
OC12
STM-16/
OC48
H
S
TRIB 1
63/32/16
3
7
8
1
X
2
1
X
TRIB 2
63/32/16
3
7
8
1
X
2
1
X
TRIB 3
63/32/16
3
7
8
1
4
2
1
X
TRIB 4
63/32/16
3
7
8
1
4
2
1
X
XCU 1
X
X
X
X
X
X
2
2
2
XCU 2
X
X
X
X
X
X
2
2
2
Maximum Port
of Each Interface
252
12
28
32
4
8
12
8
4
High Speed Tributary Cards With Protection (with CC16 Controller)
Plug-in Card
Slot
E1/T1
E3/T3
7FOM
9EoS4SW
4GESW*
Optical (SFP)
FE
GbE
GbE
STM-1/
OC-3
STM-4/
OC-12
STM-16/
OC-48
H
S
TRIB 1
63/32/16
3
7
8
1
X
2
1
X
TRIB 2
63/32/16 (B)
3(B)
7 (B)
8 (B)
1 (B)
X
2 (B)
1 (B)
X
TRIB 3
63/32/16
3
7
8
1
4
2
1
X
TRIB 4
63/32/16 (B)
3(B)
7 (B)
8 (B)
1 (B)
4 (B)
2 (B)
1 (B)
X
XCU 1
X
X
X
X
X
X
2
2
2
XCU 2
X
X
X
X
X
X
2 (B)
2 (B)
2 (B)
Maximum Port
of Each Interface
126
6
14
16
2
4
6
4
2
(B) backup/protection
